TSB-2000 Load Cell
Mettler-Toledo TSB Technical Parameters
PARAMETER | UNIT | VALUE |
Standard capacities | kg | 500,1000,2000 |
Rated output | mv/v | 2±0.002 |
Non-repeatability | %R.O | ≤ 0.01 |
Hysteresis | %R.O | ≤ ±0.02 |
Non-repeatability | %R.O | ≤ ±0.02 |
Creep error（30min） | %R.O | ≤ ±0.02 |
Zero output | %R.O | ≤1 |
Temperature Compensation Range | °C | -10 to + 40 |
Operating temperature range | °C | -20 to + 65 |
Temperature effect on output | %Load/ ˚C | ≤ ± 0.002 |
Temperature effect on zero | %R.O./ ˚C | ≤ ± 0.002 |
Input resistance | Ohms | 381 ± 4 |
Onput resistance | Ohms | 350 ± 1 |
Insulation resistance | Mega-Ohms | ≥5000 M ohm |
Excitation voltage recommended | VDC/VAC | 5~15 |
Excitation voltage maximum | VDC/VAC | 20 |
Safe overload | % | 150% |
Ultimate overload | % | 300% |
Environmental protection | IP67 | |
Cable length | m | 3.1 |
Here is the detailed information of the Load Cell TSB-2000 load cell. As a home of imported sensors, modern hero technologies(shenzhen)CO.,LTD has perfect technical services and pre - sales and after - sales support. If necessary, please contact us.
